Description

Specifications

Plug type: AU Plug

Power consumption of the Power Meter Monitor: 0.5W

Operating voltage: 240V AC

Operating current: max 10A

Wide voltage range: 200V-250V

Timing display range: 0 second~9999 days

Wattage display (Watts): 0W~9999W

Voltage display range: 0V~9999V

Current display (amps): 0.000A~10.000A

Frequency display: 0Hz~9999Hz

Wattage display range: 0.0W~9999W

Price display range: 0.00COST/KWH----99.99COST/KWH

Total KWh and cost display: 0.000KWh-9999KWh, 0.00COST----9999COST

Dimensions: Length:255mm/6.5inch

Width:70mm/2.8inch

Height:155mm/6.7inch

Description

Power meter is a monitoring and testing instrument which determines the power consumption of a connected appliance and the cost of the electricity consumed

With the help of this Power Meter Monitor, You can make certain how much your standby appliances cost, what the power factor is, whether the appliances are really charged, and how long have your appliances been charged.

Measures various parameters: power (W), energy (kWh), volts, amps, hertz, power factor and maximum power (W), time, days - kWh is vital as this is what your electricity bills are based on!

Large, clear LCD display for easy reading (screen dimension: 45mm x 70mm/1.77inch x 2.76inch).

Cumulative Kilowatt-Hour Monitor

Calculates electricity expenses

Easy electricity price setting-by pressing COST, FUNCTION, UP and DOWN button according to the instructions

Sets electricity price value which ranges 00.00COST/KWH ~99.99COST/KWH

Displays volts, amps and wattage accurate to 3%

Low power consumption.

Measure voltage, frequency, current, power factor, wattage, minimum & maximum power and record cumulative kilowatt-hour, time and electricity expenses.

Overload warning displayed on LCD.

Resetting for abnormal display or no-response of button.

7 Display Modes

Mode 1: Time/ Watt/ Cost Display

Mode 2: Time/ Cumulative Electrical Usage Display

Mode 3: Time/ Voltage/ Frequency Display

Mode 4: Time/ Current/ Power Factor Display

Mode 5: Time/ Minimum Power Display

Mode 6: Time/ Maximal Power Display

Mode 7: Time/ Price Display

Package

1x Power Meter
