Specifications

Color: Orange

Size:

2 Way: 20 x 12 x 19 mm / 0.78" x 0.47" x 0.74" (LxWxH)

3 Way: 20 x 16 x 19 mm / 0.78" x 0.63" x 0.74" (LxWxH)

5 Way: 20 x 26 x 19 mm / 0.78" x 1.02" x 0.74" (LxWxH)

Max. Voltage: EN 400 V

Current Intensity: EN 32 A

Max. Isolation: 4 kV

Max. Continuous Service Temperature: 85°C

Strip Length: 9-10mm

Compact connector with levers

Solid conductor size 0.08 to 2.5 mm² /AWG 14

Stranded conductor size 0.08 to 2.5 mm² /AWG 14

Flexible conductor size 0.08 to 4 mm² /AWG 28 - 12

Features

Security - no loose wires, tape embrittlement danger, safe and transparent visible;

Convenience - a test hole, measure the voltage without removing tape;

Quick - direct plug, plug the wrong can be pulled out, followed again;

Reliable - Each contact shrapnel independent, fit different wire diameter, safety shorting.

Package included : 64pcs wire connectors
